Description
SPECIFICATION
| Model | NHYD058 | |
| Valve Type | Screw down (type 2C) | |
| Nominal Size & Flange Drilling | Flange-X
Flange-Y Flange-Z |
PN16, DN80, BS EN 1092-2
PN16, DN80, BS EN 1092-2 PN16, DN80, BS EN 1092-3 |
| Working Pressure | 16 Bar maximum | |
| Test Pressure (Body) | Body | 25 Bar |
| Seat | 20 Bar | |
| Flange Drilling | BS 4504 Part : 2 : 1974 Table : 16/21 | |
FEATURES
| Certification | BSI Kitemark certified |
| Body material | Body material made of grey cast iron to BS 1503-3 |
| Material for the screwed outlet | Made of high tensile brass to BS 12163:2011 |
- A wiper ring is positioned above the spindle sealing to prevent the ingress of foreign matter
- Each hydrant shot is blasted (inside and outside) to SA 2 1/2 std
- All cast iron parts are thoroughly cleaned and painted
