Description
FEATURES:
| · 14 Discs to 58 Discs in different designs
· Made from high-strength steel, the frame is designed to withstand harsh field conditions and heavy use. · The discs are made from thick, high-carbon steel and are precision-cut for maximum soil penetration and cultivation. These can effectively breaks up clods, aerates the soil, and prepares a smooth seedbed for optimal planting conditions. · The gang angle can be adjusted to suit various soil types and conditions, ensuring optimal performance. · Adjustable disc spacing for customized soil cultivation. · The high-clearance frame design enables the harrow to traverse rough terrain and navigate obstacles with ease. |
· The disc harrow effectively breaks up clods, aerates the soil, and prepares a smooth seedbed for optimal planting conditions.
· – Simple design and few moving parts reduce maintenance requirements, minimizing downtime and repair costs. · Best to operate with high speeds, enabling farmers to cover large areas quickly and efficiently.
|
| MODELS | DETAILS | |||||||||
| Working Width(m) |
Weight (Kg) |
No. of Discs |
Disc Diameter (mm) |
Disc Thickness (mm) |
No. of Bearing |
Spacing Disc (mm) |
Chassis Section (mm) |
Gang Section (mm) |
Tractor (HP) |
|
| AGM/DH/14 | 1.40 | 524 | 14 | 560 | 4.5 | 4 | 230 | 80×80 | 100×80 | 40 — 50 |
| AGM/DH/16 | 1.50 | 549 | 16 | 560 | 4.5 | 4 | 230 | 80×80 | 100×80 | 50 — 70 |
| AGM/DH/18 | 1.60 | 574 | 18 | 560 | 4.5 | 6 | 230 | 80×80 | 100×80 | 70 — 85 |
| AGM/DH/20 | 1.85 | 608 | 20 | 560 | 4.5 | 6 | 185 | 80×80 | 100×80 | 75 — 88 |
| AGM/DH/22 | 1.70 | 622 | 22 | 560 | 4.5 | 6 | 230 | 80×80 | 100×80 | 88 — 110 |
| AGM/DH/24 | 2.05 | 666 | 24 | 560 | 4.5 | 6 | 185 | 80×80 | 100×80 | 110 – 115 |
| AGM/DH/28 | 2.25 | 680 | 28 | 560 | 4.5 | 6 | 230 | 80×80 | 100×80 | 115— 230 |
| AGM/DH/32 | 2.90 | 704 | 32 | 560 | 4.5 | 8 | 230 | 80×80 | 100×80 | 230 – 250 |
