Description
| · Agro1 Disc Plough is available in 2, 3 4, and 5 Discs in MF Tubular shape and Baldan Hexagonal Shape.
· This is a vital agricultural implement used for soil preparation, and its performance and durability greatly depend on the High-Strength Steel we use in the construction of the frame, disc blades, and other critical components. This provides exceptional strength, durability, and to wear and tear. · Heavy-Duty Welding job performed to construct the frame and attach components, which ensures strong, durable joints that withstand heavy loads and stress. It’s a critical for maintaining the structural integrity of the Agro1 Disc Plough.
|
· Heat-Treated Steel is used for disc blades and other wear-prone parts for the optimal hardness and strength, and enhances durability and extends lifespan, which improves durability and performance in challenging soil conditions.
· Robust Bearings are used in the disc hubs and other moving parts. · The Hubs designed for heavy-duty applications and high loads, which ensures smooth operation, reduces friction, and extends lifespan. |
| DETAILS | MODEL | ||
| AGM/DP/2D | AGM/DP/3D | AGM/DP/4D | |
| Frame Type | Tubular Stainless Steel | Tubular Stainless Steel | Tubular Stainless Steel |
| Number of Furrows | 2, 2+1 | 3, 3+1 | 4, 4+1 |
| Furrow Width | 216mm — 267 mm | 216 mm — 267 mm | 260-280 mm |
| Max. Working Depth | 240 mm | 240 mm | 240 mm |
| Longitudinal Clearance | 522 mm | 522 mm | 522 mm |
| Furrow Wheel diameter | 510 mm | 510 mm | 510 mm |
| Plain Discs Diameter | 660 mm or 710 mm x 5mm | 660 mm or 710 mm x 5mm | 660 mm or 710 mm x 6 mm |
| Bearing Sizes | Taper Roller | Taper Roller | Taper Roller |
| Weight | 276— 365 Kg | 342— 440 Kg | 400— 450 Kg |
| Tractor Compatibility | 35 — 70 Hp | 50 — 85Hp | 85 — 100Hp |
